Lead Type GPL Series

  • Home
  • Products
  • Products Catalog
  • Super Capacitor
  • Lead Type GPL Series

Products Catalog

Lead Type GPL Series
GPL Series
Lead Type
Snap-in Type NL Series
NL Series
Snap-in Type
Lead Type GMPL Series
GMPL Series
Lead Type
Lead Type PV Series
PV Series
Lead Type
Snap-in Type NV Series
NV Series
Snap-in Type

GPL Series

Lead Type

Capacitance (F) Dimension (mm) ESR/DC. Voltage (V) Operating Temp. (℃) Download Inquiry
0.5 F 8x12 1800 mΩ 2.7/2.3 V -40 to +65/+85℃
1 F 8x12 700 mΩ 2.7/2.3 V -40 to +65/+85℃
1.2 F 6.3x15 650 mΩ 2.7/2.3 V -40 to +65/+85℃
1.5F 8x14 410 mΩ 2.7/2.3 V -40 to +65/+85℃
2F 8x16 350 mΩ 2.7/2.3 V -40 to +65/+85℃
3.3F 8x20 300 mΩ 2.7/2.3 V -40 to +65/+85℃
4F 10x20 250 mΩ 2.7/2.3 V -40 to +65/+85℃
5F 10x20 160 mΩ 2.7/2.3 V -40 to +65/+85℃
6F 8x28 140 mΩ 2.7/2.3 V -40 to +65/+85℃
6F 10x20 130 mΩ 2.7/2.3 V -40 to +65/+85℃
8F 10x25 100 mΩ 2.7/2.3 V -40 to +65/+85℃
10F 10x30 85 mΩ 2.7/2.3 V -40 to +65/+85℃
15F 12.5x31.5 60 mΩ 2.7/2.3 V -40 to +65/+85℃
22F 12.5x35.5 45 mΩ 2.7/2.3 V -40 to +65/+85℃
25F 16x26 42 mΩ 2.7/2.3 V -40 to +65/+85℃
30F 16x31.5 35 mΩ 2.7/2.3 V -40 to +65/+85℃
60F 18x40 20 mΩ 2.7/2.3 V -40 to +65/+85℃
100F 22x45 15 mΩ 2.7/2.3 V -40 to +65/+85℃
100F 18x60 16 mΩ 2.7/2.3 V -40 to +65/+85℃

Send Inquiry Add Inquiry
